The REMEDY 500 is a high-productivity, independent welder powered by Made in Ritmo tracks and an on-board diesel generator. The machine features two engine speeds: 1800 rpm (Motion) and 3000 rpm (Welding).
Designed for butt welding PE and PP pipes from Ø 200 to 500 mm. Complies with International Welding Standards ISO 21307 High Pressure and ASTM F2620.
Versatile
— Working range from Ø 200 to 500 mm;
— Materials: PE, PP;
— Tracked welder;
— Climbs slopes up to 30%;
— Removable welder body for work inside the pit;
— Remote control up to 100 m.
Accurate:
— Complies with ISO 21307 High Pressure Standards and ASTM F2620 Standards;
— Removable auxiliary panel to control the cutter/heating plate;
— Welds fittings/flanges;
— Protective coating on the heating plate;
— Spotlights on the welding area.
Complete:
— Clamp opening/closing system (Ritmo Patent EP2860430);
— Hydraulically operated heating plate;
— Hydraulically operated cutter;
— Cutter with safety microswitch;
— Hydraulic side rollers;
— Independent on-board generator;
— On-board heating plate and cutter:
